Description
Model
ExpertCenter Pro ET700I W7
Operating system
Windows 11 Pro – ASUS recommends Windows 11 Pro for business.
Processor / System bus
1 x Socket LGA4677
Intel Xeon W-3400 & W-2400 Series Processors
* Refer to www.asus.com for the latest Intel CPU support list®®®
chipsets
Intel W790 Chipset®
Memory
Total Slots :
8 (4-channel)
Capacity :
Maximum up to 1024GB RDIMM
Memory Type :
Quad Channel DDR5 4800/4400 MHz, ECC RDIMM
Memory Size :
128GB, 64GB, 32GB, 16GB RDIMM
* Refer to support page for more information
* Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU.
Expansion slot
Total: 5
Location-1: PCIe x16 slot (Gen 5.0 x16 link)
Location-2: PCIe x16 slot (Gen 5.0 x16 link)
Location-3: PCIe x16 slot (Gen 5.0 x16 link)
Location-4: PCIe x4 slot (Gen 4.0 x4 link)
Location-5: PCIe x16 slots (Gen 5.0 x16 link)
Storage
Storage Controller :
Intel W790 Chipset
-4 x SATA3 6Gb/s ports
-1 x M.2_1 socket3, up to 22110 type (PCIe Gen4 x4 link), from PCH
-1 x M.2_2 socket3, up to 2280 type (PCIe Gen4 x4 link), from PCH
-SlimSAS_1 slot supports PCIe 3.0 x4 mode NVMe device
-SlimSAS_2 slot supports PCIe 4.0 x4 & SATA mode device
* Supports Intel Virtual RAID on CPU (Intel VROC) and Intel Volume Management Device ( IntelVMD)
** Intel VROC Technology supports PCIe/SATA RAID 0/1/5/10.®®®®®
Hard drive slot
3 x Internal 3.5″ Drive bays
2 x Internal 2.5″ Drive bays
辅助存储 FDD/CD/DVD
1 x 5.25″ media bay
(Options: No ODD/DVD-RW Slim ODD)
Internet
2 x Intel I226-LM 2.5GbE LAN®
Display
Supports Up to 2 2-slot NVIDIA graphics cards, including but not limited to
NVIDIA RTX 6000 ADA, 48GB GDDR6
NVIDIA RTX 4000 ADA, 20GB GDDR6
NVIDIA RTX A4000, 16GB GDDR6
NVIDIA RTX 2000 ADA, 16GB GDDR6
NVIDIA RTX A2000, 12GB GDDR6
NVIDIA A1000, 8 GB GDDR6
NVIDIA T1000, 4 GB GDDR6
NVIDIA A400, 4 GB GDDR6
NVIDIA T400, 4 GB GDDR6
*** Pro ET700I W7 does not include integrated graphics capability. A discrete graphics card is required for
display output.
**** To ensure optimal stability, an ambient temperature of under 25°C is recommended during heavy workloads.®®®®®®®®®®
前置 I/O 接口
1 x USB 20 Gbps Type-C port
2 x USB 5 Gbps ports
2 x USB 2.0 port
1 x Headphone port
1 x Microphone port®
Rear I/O Ports
2 x USB 10 Gbps ports (1 port at Type A, 1 port at Type C)
2 x USB 5 Gbps ports
4 x USB 2.0 ports
2 x LAN ports (RJ45)
1 x 7.1-channel Audio I/O ports (5+1 Audio jacks)
1 x BIOS FlashBack™ button®
Switch/LED
Front:
1 x Power Switch/LED
1 x Reset Switch
1 x HDD Access LED
1 x Fan Speed Switch ( Full speed/by fan profile setting)
Back:
1 x BIOS FlashBack
Management solutions
ASUS Control Center Express support
Intel vPro support®
Safety certification
BSMI, CE, FCC, Energy Star
Dimensions
535mm x 230mm x 448mm
21.06″ x 9.06″ x 17.64″
Weight
Net Weight : 14.28kg
Gross Weight : 21.38kg
Power supply
750W 80PLUS GOLD Single Power Supply, 100-240V, 9-4.5A, 50/60Hz, Class I
1300W 80PLUS Platinum Single Power Supply, 110-240Vac, 15-7A, 50/60Hz, Class I
Environment
Operation temperature: 10℃ ~ 35℃
Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing)
Optional items
Smart card reader
Anti-Virus CD pack
OS
DVD-ROM
Keyboard and mouse
COM port cable
Print port cable
