ASUS ThunderboltEX 5 Expansion Card

ASUS ThunderboltEX 5 expansion card — dual Thunderbolt 5 USB-C ports, up to 120 Gbps, 130 W charging, DisplayPort 2.1 and daisy-chaining for up to five devices.

Inquire for Pricing

Request a Quote
Category:

Description

ASUS ThunderboltEX 5 Expansion Card

The ASUS ThunderboltEX 5 is your gateway to a higher level of connectivity, delivering lightning-fast data transfer rates and outstanding video output. Equipped with dual Thunderbolt 5 USB-C ports, it is designed for users who demand efficiency and performance.

High-Speed Charging and Expanded Connectivity

Two USB Type-C ports together support up to 130 W of fast charging, with up to 96 W delivered to a single device — keeping laptops and accessories powered through the busiest day. Daisy-chain up to five Thunderbolt devices while maintaining full performance.

Outstanding Data Rates and Visuals

Experience data transfers of up to 120 Gbps, ideal for transcoding high-resolution content and moving large files. DisplayPort 2.1 support drives up to three 8K displays at 60 Hz with Display Stream Compression (DSC), taking gaming, content creation and media streaming to new levels of clarity and responsiveness.

With its PCIe 4.0 x4 interface and Intel certification, the ThunderboltEX 5 delivers both compatibility and reliability.

Specifications

InterfacePCIe 4.0 x4
Ports2x Thunderbolt 5 USB-C
BandwidthUp to 120 Gbps
ChargingUp to 130 W total, up to 96 W to a single device
Daisy ChainUp to 5 Thunderbolt devices
DisplayDisplayPort 2.1, up to 3x 8K @ 60 Hz with DSC
CertificationIntel certified
